2 Layered Protocols Protocols connect entities on same level, within the layer Higher layers use services provided by lower layers Layers are independent and defined by interface provided to the higher layer and required from the lower layer Entity provides an interface Entity Entity uses an interface Protocol Peer Entity Entities communicate by exchanging Protocol Data Units (PDUs) with entities on the same level

3 Why layers? Layers may be exchanged as long as interfaces stay unchanged WWW was built on top of existing TCP/IP implementations WWW does not have to care about the media (modem, Ethernet, radio link etc.) ATM can be used to transport IP packets without any changes to applications IPv6 will replace the entire IP part of the TCP/IP layer Layering makes development easier and adds flexibility

4 Protocol stacks Term protocol stack refers to all layers of a protocol family E.g. having TCP/IP stack implemented in an operating system means that part of the OS software uses device drivers (Ethernet, PPP+serial driver etc.) to receive IP packets and provides socket services to applications programs Protocol stack has nothing to do with push/pop stacks (data structures) TCP/IP by IETF is the most popular protocol stack in data communications Signaling System 7 is the most popular telecoms stack OSI protocol stack is hardly used in entirety except as a theoretical model (parts of it are in use) Implementations of protocol stacks often co-exist (OSI X.500 directory system over TCP/IP, TCP/IP communications over telephone network and SS7)

5 OSI Stack OSI IETF 7 Application Sovellus 6 Presentation Esitys Application 5 Session Yhteys 4 Transport Kuljetus Transport (TCP & UDP) 3 Network Verkko Network (IP) 2 Data link Siirto Link 1 Physical Fyysinen Physical

6 OSI Model Two (N)-level entities in different systems communicate using (N)-level protocol The services give by layer (N) to layer (N+1) are realized in (N)-level protocol by encapsulation and decapsulation Encapsulation means embedding each layer's Service Data Units (SDU) into the Protocol Data Units (PDU) of the layer immediately below it, decapsulation is the reverse process Entities at the same level in separate systems are called peer entities (N+1)-level entities are using (N)-level services through (N)- level Service Access Points ((N)-SAPs) One (N+1)-entity can be simultaneously connected to one or more (N)-SAPs One (N)-SAP is connected to one (N)-entity

7 A data packet Host SMTP IP TCP SMTP Encapsulation and decapsulation over different types of links Application contents do not change IP protocol crosses over different link layer protocols Eth IP TCP SMTP CRC Eth IP TCP SMTP CRC IP TCP SMTP PPP IP TCP SMTP FCS IP TCP SMTP PPP IP TCP SMTP FCS Router... Next router

8 Service Interface Protocols are usually internationally standardized Service interface implementations are usually operating system specific Different implementations can communicate, with common protocol Application programs need to be modified to use different interfaces Unix socket interface example: 1. open socket 2. parse address 3. connect to server 4. write request 5. read response 6. close socket

9 What Protocols do? A protocol shall be: Completely and unambiguously defined Free of dead-locks and live-locks Able to recover from all error conditions Some possible functions of protocols Addressing Connections and confirmations Error detection and correction Flow control Prioritization Multiplexing, segmentation and blocking

10 Protocol Addressing On the Internet: People usually use domain names (max 255 chars, e.g. IP-protocol uses numeric addresses (four octets, e.g ) TCP and UDP use 16 bit port addresses (e.g. 80), separate address spaces LANs and data link level protocols have their own addressing (e.g. Ethernet, six octets) Application level programs must be able to handle both IP addresses and port addresses (Unix socket service), but not data link addresses Application level protocols sometimes have their own addresses ( , URL) E.g. Telnet protocol does not do any addressing Other Telephone numbers Postal addresses

11 Connections Some protocols, like TCP provide a connection from end to end, some, like UDP are connectionless TCP must store the state and sub-states of the connection No connection Link set-up Data transmission Link disconnect Three packets to open a TCP connection and four to close Stateless and connectionless UDP is easier to implement and lighter on the network Applications must worry about data loss, e.g. domain name rerequests

12 Confirmation Protocol can provide a receipt Example: TCP header contains the sequence numbers of traffic UDP itself provides only a single datagram transmission SMTP server acknowledges when an message is received SNMP traps are not acknowledged and may be lost

13 Error control Lowest level transmission channels are analog and somewhat unreliable Data may be changed, entire frames (packets) may be lost For reliable communications we need: Error detection Error correction Data retransmission Having no error control is also option E.g. old modems and terminals

14 Checksums Trivial checksum example =10, we transmit 1,2,3,4,10 We receive: 1,3,3,4,10 and check =11 -> Error detected Our algorithm is not very good, how about: 1,3,2,4,10? Actual algorithms are more complex CRC-CCITT catches certainly all burst errors of 16 bits or less And is most likely to catch all other errors, too Parity bits Odd parity, make data element always to have odd number of ones, e.g.: > Cryptographic checksums (often called also hashes) make it very hard or impossible to replace or change the data Checksum design depends on the type of error expected Physical media errors often come in bursts

15 Error Detection Checksums can be done at different protocol levels and for different sized chucks of data Parity bit for old terminals IP has header checksum TCP and UDP checksums check both header and payload TCP/IP application level protocols do not usually do error detection, they trust TCP and UDP Encryption protocols (e.g. SSH) usuallyt have internal checksums to protect against tampering

16 Error Detected, then What? Ignore the faulty data Used with redundant real time data, like voice Freeze totally (e.g. old IBM PC and memory parity check) Report error and let higher level protocol decide Correct error The usual response And how about losing an entire frame (packet, cell) in transmission Nothing received, nothing detected Sender must wait and after a timeout retransmit Or receiver polls for more data Or it does not matter (real time voice and picture transmission)

17 Error correction Forward Error Control Add enough redundancy to data to correct errors without delay (this costs) E.g. Hamming code Usually used for time critical or one way protocols Several low level protocols also do this Backward Error Control Catch error Discard data Ask for a retransmission TCP does this

18 Flow Control What to do when the receiver s memory is full? Special characters in data stream E.g. XON/XOFF, ctrl-s/ctrl-q Used by terminals Limited receive window (e.g. TCP, Kermit) Sliding window increases efficiency The sender can not send more than a certain amount of data above what is acknowledged as received Receiver polls for individual data units Not quite a flow control, really UDP-based SNMP does this No flow control E.g. IP

19 Prioritization and Quality of Service Currently not implemented in TCP/IP Will likely change in future Operators offer QoS inside their own networks Several technologies RSVP, reservation of bandwidth Diffserv, higher service classes first MPLS, Multi Protocol Label Switching QoS services compete with trivial solutions Dedicated circuits to define the bandwidth to one customer Massive bandwidth (e.g. Gigabit Ethernet) 3G (UMTS) telephone networks will use Voice over IP (VoIP) and require QoS

20 Segmentation and Concentration Underlying layers might have special limitations Typically (Ethernet) packet maximum size is less than IP packet maximum size A protocol can perform segmentation and concentration operations to the higher level SDUs IP packet fragmentation and reassembly is a sample of this A large SDU is split to numbered smaller chunks The chunks are sent separately The receiver constructs the original SDU

21 Multiplexing and Blocking Multiplexing The joining of several data streams in one connection Usually done at low level of the network (at telephone system level) Packet data networks do statistical multiplexing inherently Everybody does not usually send at same time Blocking Packing several SDUs into one PDU

22 Transparency How to transmit any data? How to do in-band signaling? Out of band signaling = we have a separate channel for signaling E.g. classical telephony In-band signaling = control and data share same channel E.g. Internet Encapsulate data in frames Frames can have a start and stop marker Markers in data have to be passed Frame header can hold the count of objects in the frame This is what TCP/IP and Ethernet do Frames can be of fixed size (or time) ATM cells

23 Transparency, Stuffing and Data Stuffing Counting The frame is limited by markers The marker starts a control sequence One control sequence just passes data looking like the marker E.g. send the marker twice to pass the marker E.g. & > < in HTML Telnet has control codes in the data stream Data counting The header of a frame holds count of the amount of data Used by HTTP

24 Routing and switching How to get a packet to a socket over the net? Routing and forwarding: Grab each packet, read its address and push it to right direction Switching (two operations): 1. Reserve a path between the endpoints 2. Transmit data along the path

25 Routing Router is a computer with two or more network interfaces Router receives a packet at its network interface Router reads the recipient address on the packet Routing table tells the router which interface to forward this packet to Tables can be dynamic or static Each packet is an individual case IP routers can peek into TCP data, too, for security reasons A routing network can usually recover from link loss, sometimes without data loss Terms: Routing: the decision about where to forward the packet Forwarding: the actual task of moving the data

26 Circuit Switching A channel is allocated over the network for each host to host connection before any data is transferred Channels are reserved, even if no data is transmitted Used in telephone systems Other kinds of switching IP packet switching is used on LANs for performance and security Data paths are formed on the fly ATM cell switching uses small, 53-byte cells Easier to implement in hardware than variable length IP packets ATM supports bandwidth reservation A switching network can usually recover from link loss, but connections over the missing link will be broken

27 Discovering the Features of the Transmission Path A protocol can optimize its behaviour TCP discovers the Maximum Transmittable Unit for efficiency Is likely to become more important in future with the mobile devices, which move from low speed high latency 2G mobile networks to high speed low latency wireless LAN networks

28 Discovering the Features of the Protocol Entities Enables optimal use of features E.g. a handheld device might not support colour E.g. two implementations of an encryption protocol must agree on which algorithm to use E.g. compression algorithm to be used None is often considered a feature and provides a lowest common level between implementations Several encryption protocols have none as one of the standard encryption algorithms which must be implemented, while this is useful for debugging it is also potentially dangerous

29 Standardointi Perustuu Bengt Sahlinin materiaaliin

30 Standardit Standardi on yleisesti hyväksytty mahdollisimman yksiselitteinen määrittely Standardointi edistää eri valmistajien tuotteiden Ennustettavuutta Yhteensopivuutta Vaihtokelpoisuutta Standardointi voi vakiinnuttaa olemassa olevia käytäntöjä tai luoda pohjan uusien tuotteiden suunnittelulle Liki kaikkea voi standardoida Ohjelmistorajapintoja Tietoliikenneprotokollia Fyysisiä liittimiä, jännitetasoja, virtarajoja Tuotekehitysprosesseja Hyväksi havaittuja käytäntöjä (best practice -standardit)

31 De facto -standardit Tyypillisesti valmistaja, jolla on merkittävä asema markkinoilla tai syntyy luonnostaan Tuote on ensimmäinen laatuaan Avaintuote Markkinajohtajuus Varsinaisten standardien puute Esimerkiksi: Windows, PC-arkkitehtuuri kokonaisuutena Edut: Tässä ja nyt käytössä oleva menettely Riskit: Usein puutteellisesti määritelty Standardin haltija voi hyötyä tilanteesta

32 Internet Engineering Task Force (IETF) Organisaatio, joka standardoi Internetiin liittyviä asioita Etenkin protokollia Koostuu työryhmistä Määritelty tavoite Ryhmä lakkauttaa itsensä kun tavoite on saavutettu Avoin prosessi Kuka tahansa voi osallistua IETF:n toimintaan ja työryhmiin Suurin osa työstä sähköpostilistoilla Tapaamisia kolmesti vuodessa Alkuperäinen ohjausperiaate: running code and rough consensus Nykyään IETF kärsii kasvusta

33 Internet Engineering Task Force (IETF) Kaikki julkaisut ovat saatavilla maksuttomasti Request for Comments -sarja (RFCt) ftp://ftp.funet.fi/pub/doc/rfc/ Internet Draftit Työdokumentteja, yleensä ideoita tai ehdotuksia protokolliksi tai arkkitehtuureiksi Kuka tahansa voi julkaista Draftin Työryhmä voi jatkaa kehitystä

34 RFC-lajit Standards track Standardeiksi pyrkivät RFC:t Informational Tiedoksi, eivät edusta IETF:n konsensusta Experimental Tutkimustuloksia, Internetiin liittyvää tietoa Historical Vanhentuneet RFC eivät poistu vaan jäävät olemaan Best Current Practice (BCP) Dokumentoivat hyviksi havaittuja käytäntöjä STDs Muutamia erityisen tärkeitä Internet-standardeja Vain perusprotokollilla kuten TCP, UDP ja IP on STDstatus

35 3rd Generation Partnership Program (3GPP) Määrittelee kolmannen sukupolven mobiileja solukkoverkkoja (WCDMA) Julkaisee kokonaisia standardiperheitä jaksoissa (parhaillaan määritellään release 7:ää) Jäsenet ovat organisaatioita Yrityksiä, julkishallintoa Määrittelyt luodaan vaiheittain Vaihe 1 (stage 1): Vaatimukset Vaihe 2 (stage 2): Arkkitehtuuri Vaihe 3 (stage 3): Yksityiskohtainen määrittely

36 3rd Generation Partnership Program (3GPP) Toiminta on jaettu osa-alueisiin RAN: 3G-radioverkko (Radio Access Network) GERAN:GSM ja EDGE radioverkko CT: Runkoverkko ja päätelaitteet SA: Palvelut ja järjestelmäarkkitehtuuri Alueilla on tarkemmin fokusoituja työryhmiä Esim. SA WG1 keskittyy palveluihin RAN WG1 keskittyy radioverkon tasoon 1 Kaikki dokumentit ovat virallisia määrittelyjä olennaisille toiminnoille UMTS IMS MBMS WLAN interworking

37 3GPP2 Määrittelee myös kolmannen sukupolven radioverkkoa, mutta eri teknologialla (CDMA) Toimii kuten 3GPP Standardit kohtuullisen harmonisoituja 3GPP:n kanssa

38 Institute of Electrical and Electronics Engineers (IEEE) Tietoliikennepuolella keskittyy OSI-mallin kahteen alimpaan kerrokseen Ethernet, WLAN...

39 Open Mobile Alliance (OMA) Standardoi mobiilipalveluita Esim. Push to Talk och DRM Jäsenet organisaatioita

40 European Telecommunications Standards Institute (ETSI) On standardoinut mm. mobiiliverkkoja Olennainen GSM:n määrittelyssä Edelleenkin aktiivinen ETSI TISPAN Määrittelee seuraavan sukupolven nopeita lankaverkkoja (Next Generation Networks, NGN) Tavoitteena nopea IP-pohjainen (puhelin)verkko 3GPP IMS (IP Multimedia Subsystem) perustana

41 International Telecommunication Union (ITU) YK:n alainen standardointiorganisaatio Jäseninä valtioita ja suuria organisaatioita On standardoinut mm. ISDN:n, B-ISDN:n och GSM:n Rakentuu alueista ja työryhmistä Suljettu prosessi

42 Lisää tietoliikennestandardoijia World Wide Web Consortium (W3C) WWW:hen liittyvät standardit Liberty Alliance Sähköisen indentiteetin menetelmiä CERT Coordination Center (CERT/CC) Ei standardoi Edistää Internetin tietoturvaa ATM Forum Edistää ATM-verkkojen kehitystä julkaisemalla standardeja WAP Forum

43 Muita standardointiorganisaatioita International Organisation for Standardization (ISO) Standardoi kaikkia aloja Kehittänyt Open Systems Interconnection (OSI) -mallin Allliance for Telecommunications Industry Solutions (ATIS) USA:-lainen Suunnittelee mm. seuraavan sukupolven lankaverkkoja American National Standards Institute (ANSI) Julkaisee USA:n kansallisia standardeja National Institute of Standards and Technology Kehittää USA:n kansallisia standardeja eri alueille Ja paljon lisää kansallisia organisaatioita

44 Standardoinnin merkitys Tekninen yhteensopivuus ja laatu Kommunikointi ostajan ja myyjän välillä Standardeja noudattavilla tuotteilla yleensä kilpailuetu Insinööriosaamisen dokumentointi

45 Message Sequence Charts An useful graphical tool for identifying the sequence and actors of an signaling operation Notation Entities: vertical lines with names Signaling messages: named arrows Can lock participants Condition requirements Internal actions (links to other MSCs) Time constraints Order of messages Time flows down No ordering can be indicated

46 A MSC Sample MS BTS-old BTS-new BSC Channel_activate Channel_activate_ack Handover_command Handover_command Handover_access Physical_information Handover_detect Move_to_new_channel Handover_complete Handover_complete

47 Another MSC Sample (Incomplete) Browser DNS Proxy WWW-server URL_from_user Get_IP(proxy) Get_www(URL) Cache_lookup(URL) Get_IP(URL_host) Get_www(URL_path) Alt Return(www_page) Not_Found Return(www_page) Cache_store(URL, www_page)

48 MSC use Typically MSC charts are used to describe most important usage cases The charts are not always complete There are variations in the notation MSC supports also complete descriptions Protocol Data Units (PDUs) can be derived from the MSC charts Relevant information must be described PDU design Either bit/byte maps Or abstract notation of information contents and binary format derived from it

49 Lukuohje tentteihin ja välikokeisiin

50 Tenttialue Keskeiset asiat Luennoista Luentokalvoista Kirjan vastaavista alueista Harjoitustehtävistä

51 Kysymystyypit Konseptit ja akronyymit K: DNS Primary server V: Nimipalvelun palvelin, jossa ylläpidetään alueen dataa K: TCP V: Transmission Control Protocol, tarjoaa tavuvirran sovelluksille Lyhyt selitys riittää Perustele väittämä oikeaksi tai vääräksi K: TCP tarjoaa aina samanlaisen rajapinnan ohjelmoijalle V: Väärin, TCP tarjoaa saman palvelun, mutta rajapinnat saattavat vaihdella eri käyttöjärjestelmissä K: Internetissä on yhteyksiä V: Oikein, vaikka verkko ei yleensä ole tietoinen yhteyksistä, esim. TCP-yhteyden osapuolet näkevät olevansa yhteydessä V: Väärin, Internet-verkko välittää vain IP-paketteja, yhteydet ovat näennäisiä Toisinaan sekä "oikein" että "väärin" saattaa olla hyväksyttävä vastaus, pisteet annetaan perustelun mukaan

52 Kysymystyyppejä... Lyhyet kysymykset, esim. "Miten TCP-yhteys avataan?" Kirjoitettu vastaus, kuva jos sopii kysymykseen, saa käyttää ranskalaisia viivoja Tentit pyritään laatimaan mittaamaan soveltavaa osaamista, jolloin kysymys saattaisi olla "Miten Internet toimisi, jos IP paketin otsaketiedoista poistettaisi Time To Live-kenttä?" Vastauksen informaatiosisällön laajuudesta voi tehdä oletuksia pistemäärän perusteella Esseet Kirjoitettava esseemuotoon, kaaviot ja luettelot eivät saa olla pääosa vastauksessta. Esseen tulisi näyttää joltain, jonka voisi julkaista vaikkapa ammattijulkaisussa.

53 Kurssin toinen puolisko Luennot jatkuvat Käsitellään televerkkojen ja tietoturvan perusteet
