1 Rakennusautomaatiojärjestelmien standardoinnin tämän hetkinen tilanne Veijo Lappalainen VTT Kokemus rakennusautomaation standardoinnista /TC 247 Suomen edustaja TC + WG4 jäsen ISO/TC 205 WG3 Suomen edustaja TC + MA jäsen SESKO SK 205 jäsen Veijo Lappalainen 2 1

2 Standardoinnin osapuolija Standardointi - standardointijärjestöt Yhteisiä sääntöjä helpottamaan viranomaisten, elinkeinoelämän ja kuluttajien elämää. Näiden avulla lisätään tuotteiden yhteensopivuutta ja turvallisuutta, suojellaan ympäristöä ja helpotetaan kotimaista ja kansainvälistä kauppaa. Sertifiointi - sertifiointilaitokset Vaatimusten mukaisuuden osoittamista todistuksella (sertifikaatilla) tai merkillä. Sertifiointi voi kohdistua järjestelmiin; tuotteisiin; palveluihin; henkilöihin Testaus - testauslaitokset Ennen sertifikaatin myöntämistä tapahtuva vaatimusten mukaisuuden arviointi, testaus tai tarkastus. Tämän tekee riippumaton testauslaitos Veijo Lappalainen 3 Standardisoinnin maailmankartta Maailmanlaajuinen taso IEC International Electrotechnical Commission ISO International Organization for Standardization ITU International Telecommunication Union Eurooppalainen taso ELEC European Committee for Electrotechnical Standardization European Committee for Standardization ETSI European Telecommunications Standards Institute Kansallinen taso SESKO sähkötekninen ala SFS Suomen Standardisoimisliitto SFS toimialayhteisöineen Viestintävirasto teleala Veijo Lappalainen 4 2

3 Rakennusautomaation standardointikomiteat ja työryhmät / TC 247 Building Automation, Controls and Building Management WG3 Building Automation and Control and Building Management Systems WG4 Open System Data Transmission ISO / TC 205 Building environment design WG3 Building control systems design ISO/TC 205 (Building Environment Design) Maintenance Agency for EN ISO 16484, Part 5 and EN ISO 16484, Part Veijo Lappalainen 5 /TC247 organisaatiorakenne Chairman TC247 U. Wirth Siemens, CH Secretary TC247 M. Schumacher, CH WG 3 Building Automation and Control Systems + Building Management Integrated Systems and Services David Epps TAC UK WG 4 Open Data Transmission D. Dietrich TU Wien, AT P. Fischer, DE FH Dortmund WG 6 Electronic control equipment for HVAC applications, integrated room automation, controls and management systems JWG JWG CLC/TC205- /TC247 Safety and Security CLC/TC205- /TC247 Functional Safety and Security T. Chamier D. Beck D. Napar Doorway Syst. Hager Siemens, FR UK (FR) R. Cyssau, ACR FR B. Novel (SP) Veijo Lappalainen 6 3

4 /TC BACnet standardit EN ISO Data Communication Protocol BACnet *) (incl. KNX mapping) Approved & Published EN ISO Data Communication Conformance Testing BACnet Approved & Published *) Eri BACnet standardit vastaavat toisiaan seuraavasti: EN ISO 16484:2008 = ISO 16484:2007 = ANSI/ASHRAE 135: Veijo Lappalainen 7 /TC LonWorks standardit LonWorks: Open Data Communication in Building Automation, Controls and Building Management Control Network Protocol EN Part 1: Protocol stack specification Approved & Published EN Part 2: Twisted pair communication Approved & Published EN Part 3: Power Line Channel Approved & Published EN Part 4: IP communication Approved & Published pr/ts15231 Mapping between LONworks and BACnet Approved & Published pren Part 5: Implementation Guideline Approved by FV pren Part 6: Application Elements Launch Enquiry Veijo Lappalainen 8 4

5 /TC Konnex standardit Konnex: Open Data Communication in Building Automation, Controls and Building Management - Konnex Network Protocol EN Part 1: Konnex Protocol for building automation and control systems (BACS) Approved & Published EN Part 2: KNXnet/IP Protocol Approved & Published Annex of EN ISO Mapping between KNX and BACnet Approved by ISO/TC Veijo Lappalainen 9 Structure of ISO/TC 205 Building environment design ISO/TC 205 Working Groups WG 1 General principles WG 2 Design of energy-efficient buildings WG 3 Building control systems design WG 4 Indoor air quality WG 5 Indoor thermal environment WG 6 Indoor acoustical environment WG 7 Indoor visual environment WG 8 Radiant heating and cooling systems Veijo Lappalainen 10 5

6 EN ISO Building Automation and Control Systems - standard structure and status Code pren ISO EN ISO EN ISO pren ISO EN ISO Building Autom. & Cntrol Systems Part 1: Project specification and implementation Contents Design, project execution, syst. integration & commiss. Part 2: Hardware Terms & definitions for Part 2 and 3 + hw requirements Part 3: Functions With software requirements and BACS functions Lead by Status Part 4: Applications Room automation, optimization Later EN ISO Part 5: Data communication Today: BACnet; in future: : Protocol LonWorks and EIB/KNX) EN ISO pren ISO Part 6: Data communication - Conformance testing Part 7: perhaps EN EPB" Committee draft published in 2005 published in 2005 ISO -5:2007 approved With the BACnet-Standard ISO -6:2008 FDIS perhaps EN EPB - influence of BACS Prelim. discussion Veijo Lappalainen 11 KNX - status as international standard ISO/IEC series for Home Electronic Systems (HES) ISO/IEC ( ) English Information technology - Home electronic system (HES) architecture - Part 2-1: Introduction and device modularity ISO/IEC ( ) English Information technology - Home electronic system (HES) architecture - Part 3-1: Communication layers - Application layer for network based control of HES Class 1 ISO/IEC ( ) English Information technology - Home electronic system (HES) architecture - Part 3-2: Communication layers - Transport, network and general parts of data link layer for network based control of HES Class 1 ISO/IEC ( ) English Information technology - Home electronic system (HES) architecture - Part 3-3: User process for network based control of HES Class 1 ISO/IEC ( ) English Information technology - Home electronic system (HES) architecture - Part 3-4: System management - Management procedures for network based control of HES Class 1 ISO/IEC ( ) English Information technology - Home electronic system (HES) architecture - Part 3-5: Media and media dependent layers - Powerline for ISO/IEC ( ) English Information technology - Home electronic system (HES) architecture - Part 3-6: Media and media dependent layers - Twisted pair for network based control of HES Class 1 ISO/IEC ( ) English Information technology - Home electronic system (HES) architecture - Part 3-7: Media and media dependent layers - Radio frequency for network based control of HES Class 1 ISO/IEC/TS ( ) English Veijo Lappalainen 12 Information technology - Home electronic system (HES) architecture - Part 4: Home and building automation in a mixeduse building 6

7 LonWorks - status as international standard ISO/IEC FDIS , -2, -3 and -4 Liittyy :in LonWorks standardisarjan Open Data Communication in Building Automation, Controls and Building Management Control Network Protocol osiin 1-4 Part 1: Protocol stack specification Part 2: Twisted pair communication Part 3: Power Line Channel Part 4: IP communication Sähköpostiäänestys on tapahtunut , tulos ei vielä tiedossa On mahdollista, että LonWorks on hyväksytty ISO/IEC stabdardiksi Veijo Lappalainen 13 BACnet world DIS to 4: Ref. Presentation by Bill Swan Veijo Lappalainen 14 7

8 BACnet-2008 to be bublished by the end of 2008 BACnet-2004 plus Addenda a, b, c, d, e, f, m Veijo Lappalainen 15 Several BACnet Addenda in Development Standard under development g, BACnet Network Security h, a set of miscellaneous changes Status Its third public review recently completed. Its third public review recently completed i, support for lighting control systems received comments in public review in Spring 2007; currently being revised j, support for physical access control k, enhancing character set interoperability l, operator workstation profiles and BIBBs n, support for long Backup and Restore preparation times o, NAT firewall support p, the Global Group object q, BACnet over ZigBee wireless r, a set of clarifying changes s, a set of clarifying changes t, BACnet XML Recently completed its fourth public review. Is currently being revised. Recently completed its second public review. Will begin its third public review in Spring Has recently completed its second public review. Public review completed; will be published as an addendum to BACnet Has recently completed its second public review. Has recently completed its first public review. Addenda has recently completed its first public review Veijo Lappalainen 16 8
