1 SECONDARY MATERIALS IN EARTH CONSTRUCTION- PROGRAMME UUSIOMATERIAALIT MAARAKENTAMISESSA D.Sc. (Tech.) Pentti Lahtinen 1

2 -programme content 2

3 development areas 1.Product development process for materials -Technical eligibility -Environmental suitability -Production process: logistics, storage -Applications 2.Development of construction technologies 3.Development of planning and design process 4.Development of acquisition methods 5.Development of environmental legislation 3

4 -implementation 1.Product development 2.Demonstration projects 3.Regional projects 4.R&D (design processes, acquisition methods, research and development actions stipulated by environmental legislation) 5.Dissemination of information (instructions, web pages, seminars, knowledge transfer to educational institutions) 4

5 Uuma 2 organisational structure STEERING GROUP CHAIRMAN + CO-FINANCIERS Strategy, financing, implementation guidance, communication and knowledge transfer - stakeholders/ projects, support for projects EXECUTIVE COMMITTEE Responsibility for the practical implementation of the programme according to the decisions of the Steering Group Dissemination WWW-pages Guidelines Seminars Guidance and educational materials UUMA core project Industrial product development projects Materials Applications Logistics Storage Construction Equipment Quality control guidance Demonstration projetcs Fairways Regional projects Industrial ares Shopping centres Ports Sport venues Agriculture and forestry Mining Regional projects Savo-Karjala UUMA Etelä-Pohjanmaa Pirkanmaa Satakunta Oulu Metropolitan area Kaakkois-Suomi Keski-Suomi - R&D Public Acquisition procedures Environmental studies Life Cycle Assessment Design process Technical and environmental requirements - Companies Tekes EU Project budget Participation in regional projects Public funding Tekes, EU Transportation Dpt, EnvMin Other funding

6 core project participants The Finnish Transport Agency Ministry of the Environment Ministry of Employment and the Economy Ministry of Education and Culture Ministry of Agriculture and Forestry City of Helsinki Helsinki Region Environmental Services Authority Finnish Energy Industries Finnish Forest Industries Andament Ekokem-Palvelu Kuusakoski Lassila & Tikanoja Lemminkäinen Infra Morenia Ramboll Rudus Suomen Erityisjäte 6

7 Ikarsec EU Life 2012 application submitted 7

8 UUMA 2 implementation 1 Product development projects Utilisation of ash in road construction 8

9 Recovery and prerequisites for recovery Surplus soil masses can be utilised in the place of origin (in-situ) or in the vicinity of the site of origin (ex-situ) instead of being transported to landfill. They can be converted into construction/filling material by i.e. stabilisation. Binder components generated in the area can be applied for the needs of stabilisation process (industrial by-products and wastes) as such or mixed with cement or other commercial binders Recovery requires Sufficient information and skills Verification of benefits- economically competitive approach Information system serving the acquisition process

10 Examples of industrial by-products applications : ash structure The road is in a good condition seven years after repair with the use of fly ash Kangasala, the repair of Savontie 1991 Part of the road repaired with a traditional method condition after seven years 10

11 Examples of industrial by-products applications : fibre ash Rajalantie road in Luopioinen (central Finland) before repair in 1996 Rajalantie road two years after repair The fibre ash structure has performed well no signs of cracking Fibre ash material The comparison unit constructed in a traditional way has cracked. 11

12 Light traffic fairway new surface structures Case Kukkia Circlet Pilot structure Traditional crushed rock structure 12

13 Kukkia Circlet 2002 The completed road, stabilisation with rotary mixer 13

14 Puristuslujuus [MPa] Puristuslujuus [MPa] UUMA-structure investigations, Kukkia-Circlet Kuohijoki-Kyynärö UUMA-rakennetutkimukset: Kukkia Circlet, Kuohijoki-Kyynärö. Eri rakenteiden keskilujuudet. Näytteet tien keskilinjalta v v v ,0 Rakenne A, LT6%+YSe4% Rakenne B, LT6%+FTC4% Rakenne E, LT3%+RPT3%+YSe4% Rakenteet ja sideaineet 8,0 UUMA-rakennetutkimukset: Kukkia Circlet, Kuohijoki-Kyynärö. Eri rakenteiden keskilujuudet. Näytteet tien reunaosilta. v v v ,0 6,0 5,0 4,0 3,0 2,0 Rakenne A, LT6%+YSe4% Rakenne B, LT6%+FTC4% Rakenne E, LT3%+RPT3%+YSe4% Rakenteet ja sideaineet 14

15 Ash application - Construction sites in

16 Motorway Hiidenmäki - Vaheri (HIMOS) starting point

17 Mixing station in Pitkäniemi 17

18 Fly ash road Demo constructions long time bearing capacity sites: Inkoo, Leppävirta ja Koria 18

19 MW HIIDENMÄKI - VAHERI (HIMOS) STARTING POINT INCISED ROAD STRUCTURE SPREADING OF FLY ASH SPREADING OF STABILISATION AGGREGATE SPREADING OF STABILISATION AGGREGATE MILLING WITH ROTARY MIXER AND COMPACTION MW HIIDENMÄKI - VAHERI (HIMOS) READY PAVEMENT 19

20 UUSIOMATERIAALIT MAARAKENTAMISESSA Utilization of biomass ashes in infrastructure construction in Finland Highway 19 in Seinäjoki, Finland

21 CASE VUOSAARI MASS STABILISATION OF TBT SEDIMENT IN A HARBOUR IN HELSINKI

22 The completed pilot structure ( m 2 ) constituting 4 % of the harbour field (150 hectares). 22

23 Uuma2 implementation 2 Demonstration projects Roves Sampaanalanlahti 23

24 Mass stabilisation method and equipment Mass stabilisation impact on soil properties Applications Stages of mass stabilisation project Binders Design Construction Quality assurance Mass Stabilisation Handbook 24

25 Uuma2 implementation 3. Regional projects -areas of demonstration follow the borders of influence of the Centres for Economic Development, Transport and the Environment. There are 9 project areas plus the capital region whih makes the overal number of

26 Uuma2, R&D 4.R&D divided into four groups 1. Acquisition Acquisition methods Acquisition planning process 2. Technology Structures and design Technical requirements 3. Environment Research supporting the development of environmental legislation Environmental eligibility and environmental requirements 4. Life cycle Life cycle assessment and database Old structures investigations Working groups established after the workshop Workshop in March 2013 workshop: introduction -> work in groups -> proposals -> presentation to the executive committee -> presentation to steering group 26

27 Uuma2 implementation 4. R&D Case: Ports Sustainable development is fostered by a comprehensive utilisation of masses Nothing is wasted principle What is necessary in the project? Material study and testing in the beginning of the project including also poor quality, redundant soils/polluted soils, and the possibilities of their utilisation as materials Holistic mass coordination and logistic planning Proper utilisation of the good quality materials/ if necessary selling to other project (s) Material processing and stabilisation planning process Utilisation of other materials/ industrial byproducts generated in the area 27

28 Uuma2 task force and staff resources 2. Information sharing 2 A) Dissemination UUMA internet portal UUMA information services Material bank database Seminars programme database 2 B) Guidance Baseline study, guidance needs, planning of work Guidelines creation 28

29 implementation 5. Information dissemination e.g. the origin of secondary materials from energy industry source locations

30 Time table , 8/14 EMOPROJEKTIN AIKATAULU H ankesuunnittelu, o hjaus, raho itus Ohjausryhmä Työvaliokunta x x x x x x x x x x x Rahoitushaku 2. Tiedonjako ja ohjeet Valtakunnalliset seminaarit UUMa-käsikirjasto ja InfraRyl 3. Tuotteistus Vaatimukset uusiomaarakentamiselle Tuotteistusohjeet Tuotteistustyöpaja 4. T&K-työryhmät Hankinta Ympäristökelpoisuus Tekninen kelpoisuus Elinkaari 5. Demohankkeet Liikenneväylä Aluerakentaminen Teollisuus Kaivos Liikepaikka Satama 6. Aluehankkeet aloitusseminaari O 1. Savo-Karjala O valmistelu 2. Pohjois-Pohjanmaa O toteutus 3. Keski-Pohjanmaa O 4. Varsinais-Suomi O 5. Keski-Suomi O 6. Satakunta O 7. Pääkaupunkiseutu O 8. Kaakkois-Suomi O 9. Pirkanmaa O 10. Päijät-Häme O 11. Etelä-Pohjanmaa O 12. Lappi O 30
