gusto exceptional service starts with exceptional display serve overs

Transkriptio

1 gusto exceptional service starts with exceptional display serve overs

2 PROUDLY PRESENTS: YOUR PRODUCTS! THE MOTIVE Serve overs are becoming more and more popular for two reasons. The first one is the growing demand of readymade foods, both hot and cold, and also seafood. Serve overs offer the perfect presentation for these fast moving goods. The second reason deals with consumers valuing personal service. It may even become that differentiating competitive advantage that makes your store the one customers choose. Norpe offers elegant serve overs Gusto being the perfect example. Its modern design and overall steady yet light appearance invite the customer to come and take a closer look at what the display has to offer.

3

4 A HINT OF luxury IN ACTION Ideal for delicacies Gusto is a versatile serve over with many useful features. Ideal for meat, fish, cold cuts, cheese and semi-finished products, its large display area gives these delicacies the best presentation possible, which will increase sales for sure. There is a wide range of display case options available, for example the new angular front glass called Rubin.

5 Corner cover chrome Display plate Frames for bowles Display plate and wooden grill Gastronome dish Stand scale Stand scale sliding frame Paper bag holder Cutting board Display grid Ice flake grid IN USE ECOLOGY Everything and more Thanks to its reliability, ergonomics and easy to keep clean hygienic stainless steel base, Gusto has become the staff favourite. Its spacious display area presents both hot and cold ready-made foods, and also seafood, in a first-class way, every day. In other words Gusto is a unique combination of all the qualities you are after. It can be multiplexed with Inspi semivertical multideck. Part of the green team There are many things that matter when manufacturing an environmentally friendly display. For example, insulation can make a big difference. Gusto s insulation is made of HCFC free polyurethane foam. Another sustainable feature is R744 (CO2) as refrigerant. Being one of the greenest refrigerants, it greatly reduces the negative environmental impacts a display may have.

6 ACCESSORIES GUSTO SO Refrigeration Evaporator and expansion valves standard for refrigerants R404A and R744 In all models the evaporator is located under the worktop, on the back wall in the upper part of the cabinet Refrigeration is provided by gravity or forced-air cooling Refrigerated understorage (CS) Defrost cut-out thermostat in the understorage of CS models Defrost water outlet pipe of the cabinet length Model variants Display elements 125, 188, 250, 375cm Internal angle 45 IA, external angle 45 EA Condensing unit M Service model / Self Service model Non-refrigerated under-storage WS Refrigerated understorage CS Uncovered lower part P Standard EQUIPMENT External surface of galvanised steel sheet High quality powder painting Adjustable legs and plinths Drain outlet pipe with a strainer Work surface of stainless steel Insulation of HCFC free polyurethane foam Evaporator Control panel (corners 1 pc / 45, 90 ) Fan system for the front glass Cabinets with integral condensing unit Complete condensing unit withr404a refrigerant Electronic thermostat (including control and defrost cut-out thermostats, defrost timer and temperature display) Defrost water tray Optional accessories Canopy lighting (service) Expansion valves for other refrigerants Plate end panel 35mm LED lights Forced-air cooling FA Stainless steel plinths Three material choices: painted plate, stainless steel and wood Intermediate shelf with lighting (service) Lower front lighting (not available with wood decoration) Stainless steel display grid, 1-, 2- or 3-step Stainless steel display plate, 1-, 2- or 3-step Stainless steel frame for bowls, 2- or 3-step Stainless steel bowl 265x165x65 Stainless steel bowl 325x265x65 Stainless steel bowl 325x530x65 Stainless steel ice flake grids Wooden grill Stainless steel stand for scales and slicers 450x400 and 550x500 Cutting board 270x350 and 450x450 Paper bag holder (for straight display elements), length 580mm Stainless steel basket rail (not for wood decorated cabinets)

7 Stainless steel bowl 150mm for CS model Castors fitted to display elements of 125, 188 and 250cm in length Sockets (for straight display elements) Defrost heater for the upper part of the cabinet Front glass air heating Corner cover Condensing unit which is located in the machinery compartment on the left hand end (from customer s perspective) Gusto SO BED Refrigeration Evaporator and expansion valves standard for refrigerants R404A and R744 In all models the evaporator is located in the bottom of the cabinet Refrigeration is provided by forced-air cooling Defrost cut-out thermostat in the understorage of CS models Defrost water outlet pipe of the cabinet length Model variants Display elements 125, 188, 250, 375cm Internal angle 45 IA, external angle 45 EA Condensing unit M Service model / Self Service model Non-refrigerated under-storage WS Refrigerated understorage (CS) Uncovered lower part P Available only with Rubin display case. Standard equipment External surface of galvanised steel sheet High quality powder painting Adjustable legs and plinths Drain outlet pipe with a strainer Work surface of stainless steel Insulation of HCFC free polyurethane foam Forced-air cooling FA Evaporator Control panel (corners 1 pc / 45, 90 ) Fan system for the front glass Electronic thermostat (including control and defrost cut-out thermostats, defrost timer and temperature display) Optional accessories Thermometers Expansion valves for other refrigerants Plate end panel 35mm Stainless steel plinths Three material choices: painted plate, stainless steel and wood Stainless steel stand for scales and slicers 450x400 and 550x500mm Cutting board 270x350 and 450x450mm Paper bag holder (for straight display elements), length 580mm Stainless steel basket rail (not for wood decorated cabinets) Stainless steel bowl 150mm for CS model Sockets (for straight display elements) Defrost heater for the upper part of the cabinet Front glass air heating Corner cover

8 gusto TECHNICAL DATA Min. Max. Refr. Area [m 2 ] service models SO GC-WS ,03 SO GC-WS ,54 SO GC-WS ,05 SO GC-WS ,08 SO GC-CS ,54 SO GC-CS ,05 SO GC-CS ,08 SO FA-WS ,03 SO FA-WS ,54 SO FA-WS ,05 SO FA-WS ,08 SO FA-CS ,54 SO FA-CS ,05 SO FA-CS ,08 HOW TO READ THE CODE: SO Front Height Dept Height Length Measures are centimeters. ABBREVIATION F = Freezer FA = Fan assisted CS = Cold storage EA = External angle GC = Gravity cooling H = Hot counter IA = Internal angle S = Solid WS = Warm storage 0 = Remote SO IA-GC-WS ,81 SO EA-GC-WS ,87 SO IA-FA-WS ,81 SO EA-FA-WS ,87 Self-service models SO GC-WS ,03 SO GC-WS ,54 SO GC-WS ,05 SO GC-WS ,08 SO GC-CS ,54 SO GC-CS ,05 SO GC-CS ,08 SO FA-WS ,03 SO FA-WS ,54 SO FA-WS ,05 SO FA-WS ,08 SO FA-CS ,54 SO FA-CS ,05 SO FA-CS ,08 SO IA-GC-WS ,81 SO EA-GC-WS ,87 SO IA-FA-WS ,81 SO EA-FA-WS ,87 Operating Temperature C Front height 580mm Depth 1160mm Height, 1180mm Length 1250, 1875, 2500, 3750mm

9 GUSTO Freezer TECHNICAL DATA Min. Max. Refr. Area [m 2 ] SO F SO F Operating Temperature C Front height 580mm Depth 1160mm Height 1180mm GUSTO Hot Counter TECHNICAL DATA Min. Max. Heated area [m 2 ] SO H SO H Operating Temperature C Front height 580mm Depth 1160mm Height 1180mm gusto BED TECHNICAL DATA Min. Max. Refr. Area [m 2 ] Service models SO BED-FA-WS SO BED-FA-WS SO BED-FA-WS SO BED-FA-WS SO BED-FA-CS SO BED-FA-CS SO BED-FA-CS SO IA-BED-FA-WS SO EA-BED-FA-WS self-service models SO BED-FA-WS ,1 SO BED-FA-WS ,7 SO BED-FA-WS ,2 SO BED-FA-WS ,3 SO BED-FA-CS ,7 SO BED-FA-CS ,2 SO BED-FA-CS ,3 SO IA-BED-FA-WS ,8 SO EA-BED-FA-WS ,9 Operating Temperature C Front height 580mm Height, 1180mm Depth 1160mm Length 1250, 1875, 2500, 3750mm

10 GUSTO SO SO GUSTO SAFIR So GUSTO SAFIR SO GUSTO RUBIN Merkki Pvm Muutt M1437 Muoto,, malli JKH JKH M1435 SO GUSTO HOT COUNTER SO WS-FA-SAFIR SM LASIKOT, 577 NORM. KALUSTE 507 Muoto,, malli M1435 SO WS-FA-SAFIR 2121 M1437 M1611B Muoto,, malli JKH Muoto,, malli M1447 SO H-SAFIR 1:20 Muoto,, malli JKH M1447 SO GUSTO FREEZER M1443 SO58-IA-90 GUSTO 1:20 M1443 M1442 SO IA-45 GUSTO JKH M IA-90 Piirustusnumero Tavaratunnus kuvaus Yleistoleranssit m +1,-1 mm +1,-1 kg Suunn JKH Tark. Projekti IA-45 Liittyy Standardi tai luettelo Muoto, malli Lajimerkki SO WS-FA-RUBIN MITTAKUVA Ent. Uusi Kpl EA-90 EA OL OL 1140 M1441 SO58-EA-90 GUSTO 1:1 1:20 Muoto,, malli JKH M1441 M1440 SO GUSTO EA-45 Muoto,, malli JKH M1440 Muoto,, malli M1449 1:1 JKH SO FI-SAFR/RAMA M1449

11 GUSTO SO BED Merkki Pvm Muutt. So GUSTO BED RUBIN m SO WS-BED-RUBIN Liittyy So ,-1 mm +1,-1 GUSTO BED MITTAKUVA Merkki Pvm Muutt. M Piirustusnumero Standardi Muoto, malli Kpl Tavaratunnus kuvaus tai luettelo Lajimerkki Yleistoleranssit kg Suunn JKH Tark. Projekti Ent. Uusi Piirustusnumero Standardi Muoto, malli Kpl Tavaratunnus kuvaus tai luettelo Lajimerkki Yleistoleranssit m SO WS-BED-RUBIN +1,-1 mm +1,-1 Liittyy MITTAKUVA Projekti kg Suunn JKH Ent. Uusi Tark. M1614B CHOICE OF FRONT GLASS S = Service SS = Self service RAMA RAMA SAFIR SAFIR RAMA -31 RAMA -31 RAMA -31 SAFIR -32 SAFIR -32 SAFIR -32 RAMA -31 SAFIR -32 MULTIRAMA RUBIN RUBIN RAMA -31 S SAFIR -32 S MULTIRAMA -31 S rubin -35 S MULTIRAMA MULTIRAMA RUBIN RUBIN MULTIRAMA -31 RUBIN -35 RAMA RAMA SS SS SAFIR SAFIR SS SS RUBIN RUBIN SS SS MULTIRAMA -31 RUBIN -35 RAMA -31 SS SAFIR -32 SS RUBIN -35 SS Piirustuksen Piirustuksen ja ja M1446 M1446 RAMA -31 RAMA SS -31SAFIR SS -32 SAFIR SS -32 SSRUBIN RUBIN -35 SS -35 SS rama -31 ss RAMA -31 safir SS -32 SAFIR ss -32 SS RUBIN ssss GUSTO GUSTO LASIT LASIT SM LASIKOT, SM LASIKOT, NORM. NORM. VARUSTE VARUSTE Muoto,, malli Muoto,, malli Mittakaavkaava Mitta- Muoto,, malli JKH JKH JKH M1446 M1446 SFS ENMuoto, , malli M1446 JKH SFS EN M1446 GUSTO LASIT GUSTO LASIT M1446 M1446 GUSTO LASIT GUSTO LASIT M1446 SM LASIKOT, NORM. SMVARUSTE LASIKOT, NORM. VARUSTE M1446 SM LASIKOT, NORM. VARUSTE SM LASIKOT, NORM. VARUSTE Subject to alternations without notice 05/2012 Muoto,, Muoto, malli, malli JKH JKH M1446 M1446
